Wide Range of Precision Machining Services

DBC Engineering LLC’s precision machining services encompass a wide range of highly specialized processes designed to achieve the most accurate, high-quality results for various components. Our capabilities include:
O.D. and I.D. Grinding Conventional and CNC
  • Outside Diameter Grinding
  • 1/4 inch to 32 inch – LENGTH
  • 040 inch to 6 inch - DIAMETER
  • TOLERANCE: 0.0001 inch
  • Inside Diameter Grinding
  • 1/4 inch to 6 inch - LENGTH
  • .040 inch to 4 inch - DIAMETER
  • TOLERANCE: 0.0001 inch
Surface/CNC Grinding
  • Surface/CNC Grinding
  • 0.0010 inch THICKNESS up to 12 inch LONG
  • TOLERANCE: 0.0001 inch
  • Configurations: Squares, Rectangles, Triangles, Angles
Centerless Grinding
  • Centreless Grinding
  • 0.060 inch to 4 inch - LENGTH
  • 0.025 inch to 4 inch - DIAMETER
  • TOLERANCE - 0.0001 inch
  • Bar Grinding
  • To 144 inch
  • TOLERANCE - 0.001 inch
Crush Grinding
  • Crush Grinding
  • 1/4 inch to 4 inch - LENGTH
  • 0.125 inch to 3 inch - DIAMETER
  • TOLERANCE - 0.0005 inch
CNC Machining
  • CNC Machining
  • 0.030 inch to 23 inch - LENGTH
  • 0.040 inch to 4 inch - DIAMETER
  • TOLERANCE - 0.0005 inch
Electrical Discharge Machining (EDM)
  • Electrical Discharge Machining (EDM)
  • 1/4 inch to 8 inch - LENGTH
  • 0.010 inch to 1 inch - DIAMETER
  • TOLERANCE - 0.0005 inch
  • Configurations: Triangles, Squares, Rectangles, etc
Deburring
  • Deburring
  • 0.030 inch to 32 inch - LENGTH
  • 0.030 inch to 4 inch - DIAMETER
  • TOLERANCE - 100% Sharp edges with No Burrs inspected with Microscope.
Match Fit Lapping, Honing, and Pressure Testing
  • Match Fitting, Honing, Lapping
  • 0.100 inch to 6 inch - LENGTH
  • 0.060 inch to 2.5 inch - DIAMETER
  • TOLERANCE - 0.00003 inch
  • Clearance - 0.00003 inch
  • Straight Round within 0.00002 inch
  • Capable of holding 4 Finish
  • Honing/Lapping
  • 0.20 inch to 9 inch - LENGTH
  • 0.020 inch to 2.5 inch - DIAMETER
  • TOLERANCE - 0.00005 inch
  • Straight and Round: 0.00003 inch
  • Capable of holding 4 Finish
Isolation Tube/Feedback Wires
  • Tubes
  • Capable of machiningTubes with 0.002 wall thickness up to 1.5 inches long
  • Feedback wires with 0.0002 tolerance
For more information about our offerings, get in touch with us.
